5.1.4. DIO: Speciﬁcations 

IOLITE-32xDI 

Digital Input 

Isolated Input Channels 

32 

Input low level 

-1 V ~ +1 V 

Input high level 

-48 V ~ -3 V, +3 V ~ +48 V 

Input high current @ 5 V 

UIN < 1 mA 

Input high current @ 30 V 

UIN < 1 mA 

Sampling rate 

Simultaneous 40 kS/sec 

Overvoltage protection 

100 V continuous (250 Vpeak) 

Isolation voltage peak 

1000 V channel to ground & channel to channel 

Additional Speciﬁcations 

Input connectors 

Terminal block, 2 pole, 4 x 9 pole 

OMNIMATE SL 2.50 / BLF 2.50/180 

Power supply 

12 - 48 V DC 

Power out 

max. 2 A (unprotected) 

Power consumption 

Typ. 1.2 W, Max. 1.9 W 

Weight 

220 g 

Slice Dimensions 

128.4 x 115.4 x 30.1 mm 



IOLITE-32xDO 

Digital Output 

Isolated Output Channels 

32 

Compatibility 

Solid state relay 

Maximum sink current 

0.5 A 

Maximum switching voltage 

50 V 

Maximum update rate 

depending on EtherCAT master 

Isolation voltage peak 

1000 V channel to ground, no channel to channel isolation 

Additional Speciﬁcations 

Input connectors 

Terminal block, 2 pole, 4 x 9 pole 

OMNIMATE SL 2.50 / BLF 2.50/180 

Power supply 

12 - 48 V DC 

Power out 

max. 2 A (unprotected) 

Power consumption 

Typ. 1.2 W, Max. 2.0 W 

Weight 

230 g 

Slice Dimensions 

128.4 x 115.4 x 30.1 mm 



 

IOLITE® V20-1 51 / 101  
