IOLITE® 
TECHNICAL REFERENCE MANUAL 


5.4.2.1. LV: BNC Connector: Pinout 


LV connector: pin-out (BNC) 

Pin 
Name 
Description 
1 
IN+ 
Analog input 
2 
GND 
Ground 


5.4.2.2. LV: BNC Connector: Wiring diagram 
5.4.2.2.1. LV: Voltage 


 
IOLITE® V20-1 62 / 101  
