IOLITE® 

TECHNICAL REFERENCE MANUAL 



5.8.1. CNT: Speciﬁcations 

Counter 

Number of channels 

4 

Timebase 

100 MHz 

Time base accuracy 

Typical: 5 ppm, Max: 20 ppm 

Max. bandwidth 

10 MHz 

Input Filter 

500 ns, 1 μs, 2 μs, 4 μs, 5 μs and 7.5 μs 

Input Level Compatibility 

TTL (Low: <0.8 V, High >2 V) 

Input impedance 

100 kΩ pull-up to +3.3 V 

Input Protection 

±25 V continuous 

Sensor supply 

5 V / 100 mA, 12 V / 50 mA 

Counter modes 

counting, waveform timing, encoder, gear-tooth sensor 

Additional Speciﬁcations 

Input connector 

7-pin LEMO 1B series EEG.1B.307.CLNY 

Terminal block OMNIMATE Signal SL Series SL 2.50/09/90G 

Power supply 

12 - 48 V DC 

Slice Dimensions 

128.4 x 115.4 x 30.1 mm 

 

IOLITE® V20-1 86 / 101  
