IOLITE® 

TECHNICAL REFERENCE MANUAL 



Predeﬁned Levels 

0, 2, 4, 8, 16, 44 mA 

Accuracy 

±0.1 % ±2 μA (<10 mA), ±0.5 % ±5 μA (>10 mA) 

Bridge measurement 

Bridge Connection Types 

full bridge strain, ½ bridge strain, ¼ bridge strain (3-wire) 

Ranges 

2…1000 mV/V free programmable 

Internal Bridge 

Completion 

½ bridge and ¼ bridge 120 and 350 Ω 

Bridge Completion 

Accuracy 

0.05 %; TCR: 5 ppm/K (others on request) 

Internal Shunt Resistor 

100 kΩ (others on request) 

Shunt Resistor Accuracy 

0.05 %; TCR: 10 ppm/K (others on request) 

Input Short, Sensor 

Offset Adjust 

Software-selectable 

Additional Speciﬁcations 

Input connectors 

DB9 

TEDS support 

Standard + DSI adapters 

Power supply 

12 - 48 V DC 

Power Consumption 

5.4 W, Max. 11.1 W (7.9 W 120 Ω @ 5 V load, 8.8 W 350 Ω @ 10 V load) 

Weight 

340 g 

Slice Dimensions 

128.4 x 115.4 x 30.1 mm 



 

IOLITE® V20-1 75 / 101  
