Replacing the O1 motherboard
82 BEETLE /M-III - Service manual
Disengage the 4 COM interface plugs on the motherboard.
Ensure that the correct sequence is followed when plugging in later. The COM interfaces are marked on the
board.
Disengage the three power cables on the motherboard.
Remove the four screws on the motherboard.
