Interfaces Virtual LANs (VLANs)
IX10 User Guide
179
7. (Optional) Enable Spanning Tree Protocol (STP).
STP is used when using multiple LANs on the same device, to prevent bridge loops and other
routing conflicts.
a. Click STP.
b. Click Enable.
c. For Forwarding delay, enter the number of seconds that the device will spend in each of
the listening and learning states before the bridge begins forwarding data. The default is 2
seconds.
8. For Port, type a name for the VLANport and click . Generally, numbers are used for VLAN
ports.
9. Select the Device that the port uses.
10. Configure Vlan IDs:
a. Click to expand Vlan IDs.
b. Click for Add Vlan ID.
c. Type or select a unique numeric Vlan ID.
d. Click for Add Vlan ID again to add additional VLAN IDs.
11. Click Apply to save the configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the IX10
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add the VLAN:
(config)> add network vlan name
(config)>
4. Set the device to be used by the VLAN:
a. View a list of available devices:
(config network vlan vlan1)> device ?
Device: The Ethernet device to use for this virtual LAN
Format:
/network/device/loopback
/network/vlan/vlan1
Current value:
(config network vlan vlan1)>
