Virtual Private Networks (VPN) L2TPv3 Ethernet
IX10 User Guide
460
Configure an L2TPv3 tunnel
Your IX10 device supports Layer 2 Tunneling Protocol Version 3 (L2TPv3) static unmanaged Ethernet
tunnels.
Required configuration items
n
Aname for the L2TPv3 tunnel.
n
Enable the tunnel.
n
The remote endpoint IP address.
n
The local endpoint IP address.
n
The session ID.
n
The peer session ID.
Additional configuration items
n
Encapsulation type. If UDP is selected:
l
The IDfor the tunnel.
l
The IDof the peer's tunnel.
l
Determine whether to enable UDP checksum.
n
The session cookie.
n
The peer session cookie.
n
The Layer2SpecificHeader type.
n
The Sequence numbering control.
Web
1. Log into Digi Remote Manager, or log into the local Web UI as a user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
