Serial port Configure Login mode
IX10 User Guide
188
3. The serial port is enabled by default. To disable:
(config)> serial port1 enable false
(config)>
4. Set the mode:
(config)> serial port1 mode login
(config)>
5. Set the signaling interface type used on this serial port:
n
rs-232
n
rs-485
l
Enable termination if you want to enable electrical termination on this serial port:
(config)> serial port1 termination true
(config)>
The default is rs-232.
6. (Optional) Set a label that will be used when referring to this port.
(config)>path-paramlabel label
(config)>
7. Set the baud rate used by the device to which you want to connect:
(config)>serial port1 baudrate rate
(config)>
8. Set the number of data bits used by the device to which you want to connect:
(config)>serial port1 databits bits
(config)>
9. Set the type of parity used by the device to which you want to connect:
(config)>serial port1 parity parity
(config)>
Allowed values are:
n
even
n
odd
n
none
The default is none.
10. Set the stop bits used by the device to which you want to connect:
(config)>serial port1 stopbits bits
(config)>
