Digi IX10

Virtual Private Networks (VPN) IPsec
IX10 User Guide
318
b. Click to expand Local traffic selector.
c. For Type, select one of the following:
n
Address: The address of a local network interface.
For Address, select the appropriate interface.
n
Network: The subnet of a local network interface.
For Address, select the appropriate interface.
n
Custom network: A user-defined network.
For Custom network, enter the IPv4 address and optional netmask.
n
Request a network: Requests a network from the remote peer.
n
Dynamic: Uses the address of the local endpoint.
d. For Protocol, select one of the following:
n
Any: Matches any protocol.
n
TCP: Matches TCP protocol only.
n
UDP: Matches UDP protocol only.
n
ICMP: Matches ICMP requests only.
n
Other protocol: Matches an unlisted protocol.
If Other protocol is selected, type the number of the protocol.
e. For Port, type the port matching criteria.
Allowed values are a port number, a range of port numbers, or any.
f. (Optional) Click to expand Remote traffic selector.
g. For Remote network, enter the IP address and optional netmask of the remote network.
h. For Protocol, select one of the following:
n
Any: Matches any protocol.
n
TCP: Matches TCP protocol only.
n
UDP: Matches UDP protocol only.
n
ICMP: Matches ICMP requests only.
n
Other protocol: Matches an unlisted protocol.
If Other protocol is selected, type the number of the protocol.
