Digi IX10 User Manual

Virtual Private Networks (VPN) IPsec
IX10 User Guide
345
Allowed values are any number of weeks, days, hours, minutes, or seconds, and
take the format number{w|d|h|m|s}.
For example, to set Initial connection time to ten minutes, enter 10m or 600s.
n
Custom test: Tests the interface with custom commands.
If Custom test is selected, complete the following:
l
The Commands to run to test.
n
TCP connection test: Tests that the interface can reach a destination port on the
configured host.
If TCP connection test is selected, complete the following:
l
TCP connect host: The hostname or IP address of the host to create a
TCPconnection to.
l
TCP connect port: The TCP port to create a TCPconnection to.
n
Test another interface's status: Tests the status of another interface.
If Test another interface's status is selected, complete the following:
l
Test interface: The interface to test.
l
IP version: The type of IP connection, one of:
o
Any: Either the IPv4 or IPv6 connection must be up.
o
Both: Both the IPv4 or IPv6 connection must be up.
o
IPv4: The IPv4 connection must be up.
o
IPv6: The IPv6 connection must be up.
l
Expected status: The status required for the test to past.
o
Up: The test will pass only if the referenced interface is up and passing its
own SureLink tests (if applicable).
o
Down: The test will pass only if the referenced interface is down or failing its
own SureLink tests (if applicable).
e. Repeat for each additional test.
12. Add recovery actions:
a. Click to expand Recovery actions.
By default, there are two preconfigured recovery actions:
n
Update routing: Uses the Change default gateway action, which increases the
interface's metric by 100 to change the default gateway.
n
Restart interface.
b. Click .
New recovery actions are enabled by default. To disable, click to toggle off Enable.
c. Type a Label for the recovery action.
d. For Recovery type, select Reboot device.
