Applications
Use
Python
to
control
the
color
of
multi-colored
LEDs
IX10
User
Guide
643
LED
attribute
name
Color
State
Led.COM
Green
OFF
Led.ETH
ON
Led.ONLINE
OFF
Led.COM
Green
flashing
OFF
Led.ETH
FLASH
Led.ONLINE
OFF
Led.COM
Blue
OFF
Led.ETH
OFF
Led.ONLINE
ON
Led.COM
Blue
flashing
OFF
Led.ETH
OFF
Led.ONLINE
FLASH
Led.COM
White
ON
Led.ETH
ON
Led.ONLINE
ON
Led.COM
White
flashing
FLASH
Led.ETH
FLASH
Led.ONLINE
FLASH
Led.COM
Yellow
ON
Led.ETH
ON
Led.ONLINE
OFF
Led.COM
Yellow
flashing
FLASH
Led.ETH
FLASH
Led.ONLINE
OFF
Led.COM
Purple
ON
Led.ETH
OFF
Led.ONLINE
ON
