Firewall Configure Quality of Service options
IX10 User Guide
770
3. Click Firewall > Quality of Service.
4. For Add Binding, click .
The quality of service binding configuration window is displayed.
5. Enable the binding.
6. (Optional) Type a Label for the binding.
7. Select an Interface to queue egress packets on. The binding will only match traffic that is
being sent out on this interface.
8. (Optional) For Interface bandwidth (Mbit), set the maximum egress bandwidth of the
interface, in megabits, allocated to this binding. Typically, this should be 95% of the available
bandwidth. Allowed value is any integer between 1 and 1000.
9. Create a policy for the binding:
At least one policy is required for each binding. Each policy can contain up to 30 rules.
