Digi IX10

Firewall Configure Quality of Service options
IX10 User Guide
773
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a binding:
(config)> add firewall qos end
(config firewall qos 2)>
New binding are enabled by default. To disable:
(config firewall qos 2)> enable false
(config firewall qos 2)>
4. (Optional) Set a label for the new binding:
(config firewall qos 2)> label my_binding
(config firewall qos 2)>
5. Set the interface to queue egress packets on. The binding will only match traffic that is being
sent out on this interface:
a. Use the ? to determine available interfaces:
b. Set the interface. For example:
(config firewall qos 2)> interface /network/interface/eth1
(config firewall qos 2)>
6. (Optional) Set the maximum egress bandwidth of the interface, in megabits, allocated to this
binding.
(config firewall qos 2)> bandwidth int
(config firewall qos 2)>
where int is an integer between 1 and 1000. Typically, this should be 95% of the available
bandwidth. The default is 95.
7. Create a policy for the binding:
At least one policy is required for each binding. Each policy can contain up to 30 rules.
a. Change to the policy node of the configuration:
(config firewall qos 2)> policy
(config firewall qos 2 policy)>
b. Add a policy:
(config firewall qos 2 policy)> add end
(config firewall qos 2 policy 0)>
New QoS binding policies are enabled by default. To disable:
(config firewall qos 2 policy 0)> enable false
(config firewall qos 2 policy 0)>
