FCC-approved antennas (2.4 GHz)
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 101
A24-M7NF Omni-directional (Mag-mount
base station)
7.2 dBi Fixed 2 m
Panel Class Antennas
A24-P8SF Flat Panel 8.5 dBi Fixed 2 m 1.5 dB
A24-P8NF Flat Panel 8.5 dBi Fixed 2 m 1.5 dB
A24-P13NF Flat Panel 13.0 dBi Fixed 2 m 6 dB
A24-P14NF Flat Panel 14.0 dBi Fixed 2 m 7 dB
A24-P15NF Flat Panel 15.0 dBi Fixed 2 m 8 dB
A24-P16NF Flat Panel 16.0 dBi Fixed 2 m 9 dB
Table 21: Antennas approved for use with the XBee RF Modules (Cable loss is required)
Part
Number Type (Description) Gain Application* Min. Separation Required Cable-loss
Table 22: Antennas approved for use with the XBee / XBee-PRO RF Modules (Cable-loss is required)
Part Number Type (Description) Gain Application*
Min.
Separation
Required Cable-
loss
Yagi Class Antennas
A24-Y4NF Yagi (4-element) 6.0 dBi Fixed 2 m 8.1 dB
A24-Y6NF Yagi (6-element) 8.8 dBi Fixed 2 m 10.9 dB
A24-Y7NF Yagi (7-element) 9.0 dBi Fixed 2 m 11.1 dB
A24-Y9NF Yagi (9-element) 10.0 dBi Fixed 2 m 12.1 dB
A24-Y10NF Yagi (10-element) 11.0 dBi Fixed 2 m 13.1 dB
A24-Y12NF Yagi (12-element) 12.0 dBi Fixed 2 m 14.1 dB
A24-Y13NF Yagi (13-element) 12.0 dBi Fixed 2 m 14.1 dB
A24-Y15NF Yagi (15-element) 12.5 dBi Fixed 2 m 14.6 dB
A24-Y16NF Yagi (16-element) 13.5 dBi Fixed 2 m 15.6 dB
A24-Y16RM Yagi (16-element, RPSMA connector) 13.5 dBi Fixed 2 m 15.6 dB
A24-Y18NF Yagi (18-element) 15.0 dBi Fixed 2 m 17.1 dB
Omni-Directional Class Antennas
A24-F2NF Omni-directional (Fiberglass base
station)
2.1 dBi Fixed/
Mobile
20 cm 4.2 dB
A24-F3NF Omni-directional (Fiberglass base
station)
3.0 dBi Fixed/
Mobile
20 cm 5.1 dB

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
