FCC-approved antennas (2.4 GHz)
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 102
A24-F5NF Omni-directional (Fiberglass base
station)
5.0 dBi Fixed/
Mobile
20 cm 7.1 dB
A24-F8NF Omni-directional (Fiberglass base
station)
8.0 dBi Fixed 2 m 10.1 dB
A24-F9NF Omni-directional (Fiberglass base
station)
9.5 dBi Fixed 2 m 11.6 dB
A24-F10NF Omni-directional (Fiberglass base
station)
10.0 dBi Fixed 2 m 12.1 dB
A24-F12NF Omni-directional (Fiberglass base
station)
12.0 dBi Fixed 2 m 14.1 dB
A24-F15NF Omni-directional (Fiberglass base
station)
15.0 dBi Fixed 2 m 17.1 dB
A24-W7NF Omni-directional (Base station) 7.2 dBi Fixed 2 m 9.3 dB
A24-M7NF Omni-directional (Mag-mount base
station)
7.2 dBi Fixed 2 m 9.3 dB
Panel Class Antennas
A24-P8SF Flat Panel 8.5 dBi Fixed 2 m 8.6 dB
A24-P8NF Flat Panel 8.5 dBi Fixed 2 m 8.6 dB
A24-P13NF Flat Panel 13.0 dBi Fixed 2 m 13.1 dB
A24-P14NF Flat Panel 14.0 dBi Fixed 2 m 14.1 dB
A24-P15NF Flat Panel 15.0 dBi Fixed 2 m 15.1 dB
A24-P16NF Flat Panel 16.0 dBi Fixed 2 m 16.1 dB
A24-P19NF Flat Panel 19.0 dBi Fixed 2m 19.1 dB
Waveguide Class Antennas
RSM Waveguide 7.1 dBi Fixed 2m 1.5dB
Helical Class Antenna
A24-H3UF Helical 3.0dBi Fixed/
Mobile
20cm 0dB
* If using the RF module in a portable application (For example - If the module is used in a handheld device and
the antenna is less than 20cm from the human body when the device is operation): The integrator is
responsible for passing additional SAR (Specific Absorption Rate) testing based on FCC rules 2.1091 and FCC
Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields, OET Bulletin and Supplement C.
The testing results will be submitted to the FCC for approval prior to selling the integrated unit. The required
SAR testing measures emissions from the module and how they affect the person.
Table 22: Antennas approved for use with the XBee / XBee-PRO RF Modules (Cable-loss is required)
Part Number Type (Description) Gain Application*
Min.
Separation
Required Cable-
loss
