Command reference tables
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 47
AI
(v1.x80*)
Networking
{Association}
Association Indication. Read errors with the last
association request:
0x00 - Successful Completion - Coordinator
successfully started or End Device association
complete
0x01 - Active Scan Timeout
0x02 - Active Scan found no PANs
0x03 - Active Scan found PAN, but the
CoordinatorAllowAssociation bit is not set
0x04 - Active Scan found PAN, but Coordinator and
End Device are not configured to support beacons
0x05 - Active Scan found PAN, but the Coordinator
ID parameter does not match the ID parameter of
the End Device
0x06 - Active Scan found PAN, but the Coordinator
CH parameter does not match the CH parameter of
the End Device
0x07 - Energy Scan Timeout
0x08 - Coordinator start request failed
0x09 - Coordinator could not start due to invalid
parameter
0x0A - Coordinator Realignment is in progress
0x0B - Association Request not sent
0x0C - Association Request timed out - no reply was
received
0x0D - Association Request had an Invalid
Parameter
0x0E - Association Request Channel Access Failure.
Request was not transmitted - CCA failure
0x0F - Remote Coordinator did not send an ACK
after Association Request was sent
0x10 - Remote Coordinator did not reply to the
Association Request, but an ACK was received after
sending the request
0x11 - [reserved]
0x12 - Sync-Loss - Lost synchronization with a
Beaconing Coordinator
0x13 - Disassociated - No longer associated to
Coordinator
0xFF - RF Module is attempting to associate
0 - 0x13 [read-
only]
-
DA
(v1.x80*)
Networking
{Association}
Force Disassociation. End Device will immediately
disassociate from a Coordinator (if associated) and
reattempt to associate.
--
FP
(v1.x80*)
Networking
{Association}
Force Poll. Request indirect messages being held by
a coordinator.
--
Table 11: XBee / XBee-PRO commands - networking and security; sub-categories are designated within {brackets}
AT
Command
Command
Category Name and Description
Parameter
Range Default
