24 REFERENCE & INSTALLATION MANUAL
As the control panel can enable this feature for each individual
partition, select the section that corresponds to the desired partition
and turn on option [6].
[505] = Partition 1 [513] = Partition 3
[509] = Partition 2 [517] = Partition 4
7.6.1 No Movement Timer
SECTIONS [222] TO [225]
(001 to 255 X 15min.) If No Movement Auto-Arming is enabled
(see section 7.6), the control panel can send the No Movement
report code and attempt to arm the system if no movement has
occurred for the period specified by the No Movement Timer.
If No Movement Auto-Arming is disabled, the control panel can still
send the No Movement report code.
Sections [222] to [225] represent timers for partitions 1 through 4
respectively. Select the section corresponding to the desired
partition and program the time (001 to 255 x15 minutes, 000 =
disabled) without movement you wish the control panel to wait
before arming and/or sending the No Movement report code.
Example:
A user would like to arm partition 1 whenever there is no movement
for a period of 4 hours. First, enable the Auto-Arm on No
Movement feature for partition 1 by turning on option [6] in section
[505]. Then in section [222] enter 016 (16x15min. = 240min. = 4
hours).
7.7 AUTO-ARMING OPTIONS
SECTION [505], [509], [513], [517]: OPTION [7]
When using the Auto-Arming Features (see section 7.5 and section
7.6), the control panel can Force Arm or Stay Arm the selected
partition. In the section corresponding to the desired partition set
option [7]:
Option [7] ON = Stay Arming (see section 16.1.2)
Option [7] OFF = Force Arming (see section 16.1.6)
7.8 ONE-TOUCH FEATURES
[508], [512], [516], [520]: OPTIONS [1] TO [7]
The One-touch Features allow users to arm or disarm a partition
without entering access codes. Select the section that corresponds
to the desired partition and turn the desired options on or off as
listed below.
REGULAR ARM
Option [1] ON
Press and hold the [ARM] key for 2 seconds to Regular Arm (see
section 16.1.1)
STAY ARM
Option [2] ON
Press and hold the [STAY] key for 2 seconds to Stay Arm (see
section 16.1.2)
INSTANT ARM
Option [3] ON
Press and hold the [5] key for 2 seconds to Instant Arm (see
section 16.1.4)
FORCE ARM
Option [4] ON
Press and hold the [FORCE] key for 2 seconds to Force Arm (see
section 16.1.6)
DISARM
Option [5] ON
Press and hold the [DISARM] key for 2 seconds to Disarm a Stay or
Instant armed partition (see section 16.1.7)
BYPASS PROGRAMMING
Option [6] ON
Press and hold the [BYP] key for 2 seconds to perform Bypass
Programming (see section 16.1.7).
EVENT RECORD DISPLAY
Option [7] ON
Press and hold the [7] key for 2 seconds to access the Event
Record Display (see section 16.8).
7.9 EXIT DELAY
SECTIONS [226] TO [229]: 001-255 SECONDS
The Exit Delay determines the amount of time a user has to leave
the protected area before the control panel arms the partition.
Program the Exit Delay from 001 to 255 seconds, where sections
[226] to [229] represent partitions 1 through 4 respectively. The
Exit Delay applies to all zones in the selected partition except 24Hr.
Zones.
7.9.1 Exit Delay Termination
SECTIONS [505], [509], [513], [517]: OPTION [8]
The control panel can reduce the Exit Delay to 5 seconds when an
Entry Delay zone (see section 5.2.2) is opened and closed during
the Exit Delay. Since the control panel can enable this feature for
each individual partition, select the section that corresponds to the
desired partition and turn on option [8].
Example:
A user arms a partition with an Exit Delay of 45 seconds. After 15
seconds, the user leaves the protected area through the front door
(Entry Delay zone). When the door closes, the control panel
reduces the remaining Exit Delay from 30 seconds to 5 seconds.
7.9.2 No Exit Delay on Remote Arm
SECTIONS [508], [512], [516], [520]: OPTION [8]
When a user arms by using a remote control from the Liberator
TM
Wireless Bus Module, the control panel will cancel the Exit Delay
and immediately arm the system.
7.10 KEYPAD LOCK-OUT FEATURE
SECTIONS [220] AND [221]
If a consecutive number of invalid codes are entered into the
keypad, the control panel can be set to lockout access from that
keypad for a specified period. Program the number of consecutive
invalid codes from 001 to 255 (000 = disabled) into section [220].
Program the duration of the keypad lockout from 001 to 255
minutes into section [221]. Although programming 000 into section
[221] will not lockout the keypad, the control panel will transmit the
Keypad Lockout report code programmed in section [705].
