DIGIPLEX CONTROL PANEL 41
again to exit. Partitions cannot be armed if the Installer Test Mode
is enabled.
[TRBL]: START MODULE SCAN
This feature instructs the control panel to verify the status of the
modules connected to the bus. The control panel will fix any
problems with the internal organization of the modules in the
control panel. The LCD Keypads will display the serial number of
each module that has been connected to the bus.
13.7 SYSTEM DATE & TIME
SECTION [502]: OPTION [6]
The System Date and Time is programmed through the User
Menu, please refer to Clock Loss section 16.7.
13.7.1 Daylight Savings Time
By enabling option [6] in section [502], the control panel will
automatically adjust the system's clock (time) for daylight saving
changes. At 2:00AM on the first Sunday of a full weekend in April,
the control panel will add one hour to the programmed time (clock).
At 2:00AM on the last Sunday of a full weekend in October, the
control panel will subtract one hour from the programmed time
(clock).
13.8 SHABBAT FEATURE
SECTION [522]: OPTION [4]
With option [4] on, all bus detectors and keypads in the system will
no longer display any system status through the LCD and/or LEDs
between noon (12:00PM) Friday and midnight (12:00AM)
Saturday. Therefore, normal operation will be re-instated Sunday
morning at 12:00:01AM.
During the Shabbat period:
• the LCD keypads only display the date and time
• the backlight is disabled
• the LED indicators on all bus detectors and keypads in the
system are disabled
If required, a user can access all the usual commands and features
during the Shabbat period by pressing a key or, if Confidential
Mode is enabled in the keypad, by entering their access code.
When no actions have occurred for two minutes, the Shabbat
Feature will re-activate.
13.9 ACCESS CONTROL
SECTIONS [301] TO [392] AND [537]
For control panels with the Access Control feature, refer to the
following documents:
Digiplex Access Control: Reference and Installation Manual
Digiplex Access Control: Control Panel Programming Guide
Digiplex Access Control: LCD Keypad Programming Guide
Digiplex Access Control: User’s Manual
13.10 MODULE RESET
SECTION [951]
To reset a module that is connected to the bus to its default values,
key in the module's serial number into section [951].
13.11 LOCATE MODULE
SECTION [952]
If you wish to locate a specific module (e.g. detector, zone
expansion module, etc.) connected to the bus, key in the module's
serial number into section [952]. The green LOCATE LED on the
module will begin to flash until the serial number is re-entered into
section [952] or the appropriate tamper or unlocate switch on the
module is pressed.
13.12 MODULE PROGRAMMING
SECTION [953]
All modules connected to the bus are programmed through the
control panel. Therefore, if you wish to program a module, enter
section [953] to enter Module Programming Mode (see section 4.2)
and key in the module's serial number. At this point, any sections
entered will be those of the selected module. For details on how to
program the modules, refer to the module's Installer’s Guide or the
module’s Programming Guide. To exit this mode, press the [CLEAR]
key until you are in Normal Mode.
13.13 MODULE BROADCAST
SECTION [954]
This feature allows you to copy the contents of all programming
sections from one bus module to one or more of the same type of
module. In section [954], key in the serial number of the source
module, then enter the serial numbers of all the destination
modules you wish to program and press [ACC].
For example:
You've completed the programming of a zone expansion module
(sn#30540033) and you wish to program another two zone
expansion modules (sn#30540075 and sn#30412100) with the
same settings and options:
1) Press and hold the [0] key
2) Key in the Installer Code
3) Enter [954]
4) Enter 30540033, 30540075, and 30412100
5) Press [ACC].
The control panel will automatically copy the contents of 30540033
into the other two zone expansion modules.
13.14 REMOVE MODULE
SECTION [955]
After entering section [955], the control panel will scan all modules
connected to the bus and display their serial numbers on the LCD
keypads screen. If any missing modules are detected (i.e. detector
removed from the bus) during this scan, the control panel will erase
the module's serial number and remove the module from the
control panel's memory.
13.15 SERIAL NUMBER VIEWING
SECTION [900]
This feature allows you to view the serial number of the control
panel as well as the serial numbers of all modules connected to the
bus.
