DIGIPLEX CONTROL PANEL 31
9.2.13 Special Reporting Codes
SECTION [717] AND [718]
Whenever the system generates one of the following instances, the
control panel can send the appropriate report code to the central
station identifying the type of system occurrence:
Section [717]
• Cold Start: the control panel was completely shutdown (total
power loss) and the control panel was re-started
• Warm Start: the control panel performs a reset due to any
sudden problem other than power loss
• Test Report: a test report has been generated automatically
(see section 9.8)
Section [718]
• WinLoad Access: the control panel has ended communication
with WinLoad
• Installer In: installer has entered the programming mode
• Installer Out: installer has exited the programming mode
9.3 CENTRAL STATION PHONE #
SECTIONS [561] TO [564]
The Digiplex Control Panel can dial up to 4 different central station
telephone numbers. Sections [561] to [564] represent central
station telephone numbers 1 through 4. You can enter any digit
from 0 to 9 and any special keys or functions (see Table3, Special
Telephone Number Keys) up to a maximum of 32 digits. Please
refer to Event Call Direction in section 9.6 and Reporting Formats
in section 9.5 for more information on how these telephone
numbers are used.
Table 3: Special Telephone Number Keys
9.4 PARTITION ACCOUNT #
SECTIONS [551] TO [554]
All report codes are preceded by a 4-digit or 3-digit Partition
Account Number to ensure correct identification of active zones in
a partitioned system. Sections [551] to [554] represent the
Partition Account Codes for partitions 1 through 4. Partition
account numbers can be any hexa-digit from 0 to F.
Example:
If a zone generates an alarm in Partition 1, the control panel will
send Partition Account Number 1 followed by the appropriate
report code.
Only the SIA format supports the [0] = 0 digit in its
account numbers. Account numbers that use any
other reporting format do not support the [0] = 0 digit.
You must enter the [STAY] = A digit in its place. When
using the SIA Format, the control panel will only use Partition
Account Number 1 programmed in section [551], but the
report code will include the partition number.
9.5 REPORTING FORMATS
SECTION [550]
The Digiplex Control Panel can use a number of different reporting
formats and each of the four Central Station Phone Numbers (see
section 9.3) should be programmed with the same reporting format
unless it is combined with a Pager format. The first digit entered
into section [550] represents the reporting format (see Table4,
Reporting Formats) used to communicate with central station
telephone number 1, the second digit represents telephone
number 2 and so forth.
Table 4: Reporting Formats
9.5.1 Standard Pulse Formats
The Digiplex Control Panel can use the Ademco slow, Silent Knight
fast and Sescoa standard pulse reporting formats (see Table4,
Reporting Formats).
9.5.2 Ademco Express
The Ademco Express is a high-speed reporting format that
communicates 2-digit (00 to FF) report codes programmed into
sections [600] to [718]. Unlike other Ademco formats, the Ademco
Express does not use the Contact ID Report Codes.
9.5.3 Ademco Contact ID
Ademco Contact ID is a fast communicator format that uses tone
reporting instead of pulse reporting. This communicator format also
uses a pre-defined list of industry standard messages and report
codes that will suit most of your basic installation needs. To
manually program the report codes, key in the 2-digit hexadecimal
values from the Contact ID Report Codes List in the Programming
Guide into the desired report codes in sections [600] to [718] (see
section 9.2). You can also enter 00 to disable reporting or FF to
use the default report code from the Automatic Report Code List in
the Programming Guide. To automatically program a set of default
Contact ID codes, refer to section 9.13.
9.5.4 SIA FSK
SIA FSK is a fast communicator format that uses tone reporting
instead of pulse reporting. This communicator format uses a pre-
defined list of industry standard messages and report codes that
will suit most of your basic installation needs. To manually program
the report codes, enter 00 to disable reporting or FF to use the
default report code from the Automatic Report Code List in the
Programming Guide. To automatically program a set of default SIA
FSK codes, refer to section 9.13.
[STAY] = *
[FORCE] = #
[ARM] = Switch to Tone Dialing (T)
[DISARM] = Wait for second dial tone (W)
[BYP] = 4-second pause (P)
[MEM] = Insert
[TRBL] = Delete
[ACC] = Delete from cursor to the end
0 = Ademco slow (1400Hz, 1900Hz, 10BPS)
1 = Silent Knight fast (1400Hz, 1900Hz, 20BPS)
2 = Sescoa (2300Hz, 1800Hz, 20BPS)
3 = Ademco Express (DTMF 4+2)
4 = Reserved for future use
5 = Ademco Contact ID
6 = SIA FSK
7 = Pager
