36 REFERENCE & INSTALLATION MANUAL
11.2.1 PGM Deactivation Event
SECTIONS [401], [403], [405], [407], AND [409]
If the PGM Deactivation Option is set to Follow (see section 11.2),
the PGM will deactivate when the programmed event occurs
unless the first digit of the PGM Activation Event is 1 to 7. To
program a PGM Deactivation Event:
1) Enter the section that represents the desired PGM.
PGM1 = [401] PGM4 = [407]
PGM2 = [403] PGM5 = [409]
PGM3 = [405]
2) Enter the first digit (see PGM Programming Table on page37)
where each digit from 0 to F represents a specific group of
events.
3) Enter the second digit, which can be any digit from 0 to F
depending on the first digit.
4) After entering the second digit, use the Feature Select method
(enable/disable options [1] to [8]) to select up to eight specific
events as detailed in the PGM Programming Table.
If the PGM Deactivation Option is set for Timed (see section 11.2),
the PGM will ignore the PGM Deactivation Event.
11.2.2 PGM Delay Timers
SECTIONS [250] TO [254]
To program the PGM Delay Timers, enter the section that
corresponds to the desired PGM, where sections [250] to [254]
represent PGM1 to PGM5 respectively, and enter a value from 001
to 255. The value entered is either in seconds or minutes as
determined by the PGM Time Base Selection (see section 11.2.3).
11.2.3 PGM Time Base Selection
SECTION [503]: OPTIONS [1] TO [5]
The PGM Time Base Selection determines whether the Delays
programmed in sections [250] to [254] are in minutes or seconds.
Options [1] to [5] represent PGMs 1 to 5 respectively. Each PGM
Delay Timer can be set to minutes or seconds by turning the
options on or off in section [503]:
Option ON = Minutes
Option OFF = Seconds
11.3 PGM1 IS SMOKE INPUT
SECTION [502]: OPTION [7]
Enabling option [7] in section [502] will set PGM1 to act as a zone
input for two-wire smoke detectors. When programming Zone
Numbering (see section 5.1), the control panel will recognize
PGM1 as input number 255. For more information on how to
connect two-wire smoke detectors, please refer to section 3.15.1
