DIGIPLEX CONTROL PANEL 29
9.1 REPORTING ENABLED
SECTION [521]: OPTION [3]
This option will either enable or disable event reporting. With option
[3] on in section [521], Event Reporting will be enabled. When an
event (e.g. open zone) occurs in the system, the control panel
verifies if a report code was programmed in the section
corresponding to the event. If a report code is programmed, the
control panel will dial the central station telephone number defined
by the Event Call Direction feature. When the central station
answers, the control panel will transmit the system account code,
followed by the programmed report code.
9.2 REPORT CODES
A report code is a 2-digit or 1-digit hexadecimal value, consisting of
digits from 0 to F. Each section from [600] to [718] represents a set
of four specific events. Each of these events can be programmed
with a 1-digit or 2-digit report code. For a comprehensive list of the
events and their relevant sections, please refer to the Digiplex
Programming Guide. Please note that only the Ademco Slow,
Silent Knight, Sescoa and Pager Formats support 1-digit report
codes.
When a specific event occurs, the control panel will send the
programmed report code to the central station. The method of
report code transmission is defined by the following two items:
Reporting Formats (see section 9.5) and Event Call Direction
(see section 9.6). These two items define how and where the
report codes are transmitted. If you are using the Ademco CID or
SIA formats, an Auto Report Code Programming feature is
available. Using this feature, sections [600] to [718] do not have to
be manually programmed (see section 9.13). The following sub-
sections provide a brief description of the events that the control
panel can report:
9.2.1 Arming Report Codes
SECTIONS [600] TO [625]
A report code can be programmed for each of the 96 User Access
Codes and 8 keyswitch zones. When using an access code or
keyswitch to arm one or more partitions, the control panel can send
the appropriate report code to the central station identifying which
access code or keyswitch zone was used to arm the partition(s).
9.2.2 Special Arming Report Codes
SECTIONS [626] TO [627]
Whenever the system is armed using one of the special arming
features, the control panel can send the appropriate report code to
the central station identifying how the system was armed.
Section [626]
• Auto-Arming (see section 7.5)
• PC Arming: system armed using WinLoad (see section 15)
• Late to Close (see section 7.5)
• No Movement (see section 7.6)
Section [627]
• Partial Arming: when partitions are Stay Armed, Instant Armed
or armed with bypassed zones
• Quick Arming: partitions armed using any of the One-Touch
Arming features (see section 7.8)
9.2.3 Disarming Report Codes
SECTIONS [628] TO [653]
A report code can be programmed for each of the 96 User Access
Codes and 8 keyswitch zones. Whenever an access code or
keyswitch is used to disarm one or more partitions, the control
panel can send the appropriate report code to the central station
identifying which access code or keyswitch was used to disarm the
partition(s). The control panel can transmit the report codes every
time a partition is disarmed or only when disarmed following an
alarm. Please refer to Disarm Reporting Options in section 9.10.
9.2.4 Special Disarming Report Codes
SECTION [654]
Whenever using one of the special disarming features listed below,
the control panel can send the report code to the central station
identifying how the system was disarmed. The control panel can
transmit the report codes every time a partition is disarmed or only
when disarmed following an alarm. Please refer to Disarm
Reporting Options in section 9.10.
Section [654]
• Cancel Auto-Arm: if a user disarms the partition during the
Auto-Arm 60-second delay
• Quick Disarm: partitions disarmed using the One-Touch
Disarming feature (see section 7.8)
• PC Disarm: when WinLoad is used to disarm the system
9.2.5 Zone Alarm Report Codes
SECTIONS [655] TO [666]
A report code can be programmed for each of the 48 available
zones. Whenever a zone generates an alarm, the control panel can
send the appropriate report code to the central station identifying
which zone generated an alarm.
9.2.6 Zone Restore Report Codes
SECTIONS [667] TO [678]
A report code can be programmed for each of the 48 available
zones. The control panel can transmit these report codes to the
central station when the zone closes after generating an alarm or
once the bell has cut-off after alarm generation (see section 8.2).
Please refer to Zone Restore Report Options in section 9.11.
9.2.7 Special Alarm Report Codes
SECTIONS [679] TO [680]
Whenever the system generates an alarm due to one of the
conditions listed below, the control panel can send the appropriate
report code to the central station identifying the type of alarm.
Section [679]
• Emergency Panic: if the panic keys [1] and [3] have been
pressed (see section 8.5)
• Auxiliary Panic: if the panic keys [4] and [6] have been pressed
(see section 8.5)
• Fire Panic: if the panic keys [7] and [9] have been pressed
(see section 8.5)
• Recent Closing: if after having armed the system, an alarm is
generated within the Recent Close Delay (see section 9.7)
