32 REFERENCE & INSTALLATION MANUAL
9.5.5 Pager Reporting Format
Using this format allows the control panel to transmit report codes
to a pager. A pound symbol “#” is automatically generated after the
report code. Please refer to Pager Delay in section 9.12.
9.6 EVENT CALL DIRECTION
SECTIONS [522] TO [536]
As shown in Figure 9-1 on page 28, the control panel events are
divided into three event groups for each partition and two global
event groups. Each event group can be programmed to dial up to
four central station telephone numbers and to use one of the four
telephone numbers as a backup. The numbers are dialed
sequentially starting from 1, skipping any disabled numbers and
stopping once all selected telephone numbers have been reached.
If the control panel still fails to report to a central station telephone
number after reaching the Maximum Dialing Attempts (see section
9.6.1), the control panel will dial the selected backup telephone
number unless the Alternate Backup Option is enabled (see
section 9.6.3). When the Alternate Backup Option is enabled, the
control panel will dial the backup number after every failed attempt.
9.6.1 Maximum Dialing Attempts
SECTION [257]
The number (001 to 255) programmed into section [257]
determines how many times the control panel will dial the same
central station telephone number before proceeding to the next
number. Also refer to section 9.6.3.
9.6.2 Delay Between Dialing Attempts
SECTION [258]
This delay will determine the amount of time the control panel will
wait between dialing attempts. This delay can be set from 001 to
255 seconds.
9.6.3 Alternate Backup Option
SECTION [522]: OPTION [6]
With option [6] enabled in section [522], the control panel will dial
the selected backup telephone number after every failed attempt to
contact a central station telephone number. Otherwise (option [6]
off), the control panel will only dial the backup telephone number
after the Maximum Dialing Attempts (see section 9.6.1) to one
central station telephone number have failed.
9.7 RECENT CLOSE DELAY
SECTION [219]
If after having armed the system, an alarm is generated within the
period programmed into section [219] (000 to 255 seconds), the
control panel will transmit the Recent Close report code
programmed into section [679].
9.8 AUTO TEST REPORT
SECTIONS [261] AND [270]
The control panel will transmit the test report code programmed
into section [717] after the number of days (000 to 255)
programmed into section [261] has elapsed and at the time (00:00
to 23:59) programmed into section [270].
9.8.1 Hourly Test Transmission
SECTION [522]: OPTION [3]
Alternatively, the control panel can transmit the test report code
programmed into section [717] every hour. Turn off option [3] to
disable this feature. Program the minute of each hour (00:00 to
00:59) it sends the test report into section [270].
9.9 POWER FAIL REPORT DELAY
SECTION [260]
The control panel will delay transmission of the AC Failure report
code programmed into section [712] by the period programmed
into section [260] (000 to 255 minutes).
9.10 DISARM REPORTING OPTIONS
SECTIONS [506], [510], [514], [518]: OPTION [7]
Since the control panel can enable the Disarm Reporting Options
for each individual partition, select the section that corresponds to
the desired partition and turn option [7] on or off as desired.
Sections [506], [510], [514], [518] represent partitions 1 to 4
respectively.
REPORT ON DISARM AFTER ALARM ONLY
Option [7] ON
The Digiplex Control Panel will send Disarming Report Codes (see
section 9.2.3) to the central station only when the system is
disarmed following an alarm.
REPORT ON DISARM
Option [7] OFF
The Digiplex Control Panel will send the Disarming Report Codes
(see section 9.2.3) to the central station whenever a partition is
disarmed.
9.11 ZONE RESTORE REPORT OPTIONS
SECTION [522]: OPTION [8]
REPORT ON ZONE CLOSURE
Option [8] ON
The control panel will send the Zone Alarm Restore report codes
(see section 9.2.6) to the central station as soon as the zone
returns to normal (zone closure) or upon disarming
REPORT ON BELL CUT-OFF
Option [8] OFF
The control panel will send the Zone Alarm Restore report codes
(see section 9.2.6) to the central station when the Bell Cut-Off
Timer has elapsed or when the alarm has been disarmed (see
section 8.2).
9.12 PAGER DELAY
SECTION [259]
When using the Pager Reporting Format (see section 9.5.5), the
control panel will wait for the delay period programmed into section
[259] (001 to 060 seconds) before uploading the report codes to
the pager. This is to allow time for the pager system to provide a
dial tone or to bypass the welcome message before sending data.
