42 REFERENCE & INSTALLATION MANUAL
With the LCD Keypad: After entering section [900], the keypad
will display the eight-digit serial number of the control panel. Use
the [p] and [q] keys to scroll through the serial number of each
module connected to the bus.
With the LED Keypads: After entering section [900], the serial
number of the control panel will illuminate one number at a time as
you press the [p] key ([10] LED represents zero). The keypad will
emit a confirmation beep to indicate that it is now displaying the
serial number of the next module connected to the bus.
13.16 POWER SAVE MODE
SECTION [504]: OPTIONS [4]
When the control panel is running on the backup battery (no AC),
the control panel can set all keypads into a “sleep mode” or Power
Save Mode. In Power Save Mode the keypad's backlight and LEDs
will be disabled until a key is pressed, an alarm occurs or an Entry
Delay is triggered.
13.17 AUTO TROUBLE SHUTDOWN
SECTION [218]
If, in a 24-hour period, a trouble has occurred more than the
number of times programmed in section [218], the control panel
will no longer report this trouble. Enter a value (001 to 015, 000 =
disabled) into section [218]. Please note that each trouble has its
own counter. This counter is reset every day at midnight or when a
Module Scan is performed (see section 13.6). Also, note that it
cannot be set to more than 15.
13.18 NO AC FAIL DISPLAY
SECTION [503]: OPTION [7]
With option [7] in section [503] enabled, the control panel will not
display the AC Failure as a trouble. This means that when an AC
Failure occurs when this option is on:
• the AC LED will extinguish
• the trouble will not appear in the Trouble Display
• the keypad will not beep to indicate the trouble
• the AC Failure report code will be reported.
