Table of Contents

Default Chapter3
- Table of Contents3
Introduction6
- Features6
- Specifications6
Accessories7
Installation9
- Location & Mounting9
- Earth Ground9
- AC Power9
- Backup Battery9
- Auxiliary Power Terminals9
- Telephone Line Connection9
- Bell/Siren Output9
- Calculating Power Requirements11
- Programmable Outputs12
- Bus Zone Connections13
- Single Zone Connections13
- Double Zone Connections14
- Keypad Zone Connections14
- Keyswitch Connections14
- Fire Circuits14
- Connecting the ZX415
Programming Methods16
- Panel Programming Mode16
- Module Programming Mode16
- Feature Select Programming16
- Decimal Programming16
- Hexadecimal Programming16
- Level Programming16
- Paradox Memory Key17
Zone Programming18
- Zone Numbering19
- Zone Definitions19
- Zone Partition Assignment20
- Zone Options20
- Input Speed21
- EOL Zones21
- Zone Doubling (ATZ)22
Keyswitch Programming23
- Keyswitch Numbering24
- Keyswitch Definitions24
- Keyswitch Partition Assignment24
- Keyswitch Options24
Arming & Disarming Options25
- Arming Follows Partition25
- No Arming on Battery Fail25
- No Arming on Tamper25
- No Arming on Supervision Loss25
- Timed Auto-Arming25
- No Movement Auto-Arming25
- Auto-Arming Options26
- One-Touch Features26
- Exit Delay26
- Keypad Lock-Out Feature26
- Maximum Bypass Entries27
- Display "Bypass" if Armed27
- Bell Squawk27
- Ring-Back27
- Switch to Stay Arming27
Alarm Options28
- Bell/Alarm Output28
- Bell Cut-Off Timer28
- Wireless Transmitter Supervision Options28
- Tamper Recognition Options28
- Keypad Panic Options29
Event Reporting30
- Reporting Enabled31
- Report Codes31
- Central Station Phone33
- Partition Account33
- Reporting Formats33
- Event Call Direction34
- Recent Close Delay34
- Auto Test Report34
- Power Fail Report Delay34
- Disarm Reporting Options34
- Zone Restore Report Options34
- Pager Delay34
- Auto Report Code Programming35
Dialer Options36
- Telephone Line Monitoring36
- Tone/Pulse Dialing36
- Pulse Ratio36
- Busy Tone Detection36
- Switch to Pulse36
- Bell on Communication Fail36
- Dial Tone Delay36
Programmable Outputs37
- PGM Activation Event37
- PGM Deactivation Option37
- PGM1 Is Smoke Input38
Pgm Programming Table39
System Settings & Commands42
- Hardware Reset42
- Software Reset42
- Battery Charge Current42
- Installer Code Lock42
- Partitioning42
- Installer Function Keys42
- System Date & Time43
- Shabbat Feature43
- Access Control43
- Module Reset43
- Locate Module43
- Module Programming43
- Module Broadcast43
- Remove Module43
- Serial Number Viewing43
- Power Save Mode44
- Auto Trouble Shutdown44
- No AC Fail Display44
Access Codes45
- Installer Code45
- Access Code Length45
- System Master Code45
- Programming Access Codes45
- User Options45
- User Partition Assignment46
- Access Control46
- Multiple Action Feature46
Winload Software47
- Answering Machine Override47
- Ring Counter47
- Panel Identifier47
- PC Password47
- PC Telephone Number47
- Call Winload47
- Answer Winload47
- Event Buffer Transmission47
- Call Back Feature47
User Features48
- Arming and Disarming Features48
- Bypass Programming48
- Chime Zones49
- Access Codes49
- Normal and Confidential Modes49
- Keypad Settings49
- Trouble Display50
- Event Record Display51
Index52
Fcc Warnings56
Warranty57
