DIGITAL-LOGIC AG PCCP5 Manual V2.3
102
BFx-Settings for different CPU’s.
BF0 BF1 BF2 BUS CLK INTEL P1 MMX MMX-L AMD-K6 AMD-K6
1 0 1 200 3.0 3.0 3.0 3.0
0 0 1 166 2.5 2.5 4.0 2.5 2.5
0 1** 1 133 2.0 2.0** 2.0 2.0 or 6.0*
1 1** 1 100/233 1.5 1.5**/3.5 3.5 3.5
1 0 0 333 5.0 5.0
0 0 0 2.5 4.5 4.5
0 1 0 266/300 4.0/4.5 4.0/4.5
1 1 0 366 5.5 5.5
* Model 8 (F:8)
** MMX (330Ω pull up {MSM-P5} )
1 OPEN jumper
0 CLOSED jumper
Remarks: AMD’s need a customized BIOS.
NEW VGA BIOS SELECTION: (needs a 16multibios):
J82-J85 Direct VGA-BIOS select J85 J84 J83 J82
CRT BIOS 0 open open open open
LCD 1 BIOS 1 open open open close
LCD 2 BIOS 2 open open close open
LCD 3 BIOS 3 open open close close
LCD 4 BIOS 4 open close open open
LCD 5 BIOS 5 open close open close
LCD 6 BIOS 6 open close close open
LCD 7 BIOS 7 open close close close
LCD 8 BIOS 8 close open open open
LCD 9 BIOS 9 close open open close
LCD 10 BIOS 10 close open close open
LCD 11 BIOS 11 close open close close
LCD 12 BIOS 12 close close open open
LCD 13 BIOS 13 close close open close
LCD 14 BIOS 14 close close close open
LCD 15 BIOS 15 close close close close
Settings written in bold are defaults!
