9 ETHERNET LAN
9.1 Ethernet IO-Address and IRQ selection
The Ethernet interface is configured with the values stored in an EEPROM. The default values are:
Jumper
Configuration
J41
IOS0
J42
IOS1
J43
IOS2
Base
address
IRQ BUS INTERFACE
0 closed closed closed 340 5 8 AUI/COAX
1 open closed closed 340 10 16 AUI/COAX
2 closed open closed 320 11 16 AUI/COAX
3 open open closed 300 2/9 8 AUI/COAX
4 closed closed open 340 5 8 10BASE-T
5 open closed open 340 10 16 10BASE-T
6 closed open open 320 11 16 10BASE-T
7 open open open Software downloadable configuration
On the board, the default configuration and the selected configuration are labeled. The label also contains
the unique node address:
Label example:
NODE: aabbccddeeff TYPE: B
0 340 i5 8 AUI
1 340 i10 16 AUI
* 2 320 i11 16 AUI
3 300 i5 8 AUI
4 340 i5 8 10BASE-T
5 340 i10 16 10BASE-T
6 320 i11 16 10BASE-T
The asterisk * in front of the configuration 2 line marks the selected configuration. You can change the hard-
ware configuration by modifying the jumper IOS0 - IOS2.
The software downloaded configuration ise recommended only for custom cases, where the values must be
altered, without soldering the jumpers onboard. The downloaded configuration works only with Novell V3.11
and Novell Lite and all other ODI driver NOS.
For OS/2, NT and UNIX applications always use the hardware configuration, because the drivers are
adapted only for hardware configuration schemes.
