DIGITAL-LOGIC AG PCCP5 Manual V2.3
125
11 SOUNDPORT DRIVER INSTALLATION
Since boardversion V2.2, the sound chip is an ESS1869 and therefore, please refer always to all the
ESS drivers and programs
The power- amplifier needs a +12V power supply.
Please be sure, that the +12V / 200mA is connected to the external main power input.
To download the latest chip producer drivers, go to:
http://www.esstech.com or http://www.digitallogic.com
11.1 DOS Driver
ESSCFG.EXE allows the user to configure the ESS sound chip with a base address, a DMA chanel, an IRQ
channel, and an address for the MPU-401 port, if a wavetable is supported by the sound card.
ESSVOL.EXE allows the user to configure the output volume level of the mixer in the sound chip.
Type
ESSCFG.exe [Enter]
to run the program or
ESSCFG.EXE /? [Enter]
for help.
Type
ESSVOL.EXE [Enter]
to run the program or
ESSVOL.EXE /? [Enter]
for help.
Typical parameters are:
address : 220
DMA : 1
IRQ : 5
MPU-401 : 330
