3.1 Expansion Bus
The bus currents are:
Output-Signals: IOH: IOL:
D0 - D16 24mA 24mA
A0 - A23: 24mA 24mA
MR,MW,IOR,IOW,
RES,ALE,AEN,C14 24mA 24mA
DACKx, DRQx,INTx,
PSx, OPW 24mA 24mA
Input-Signals: Logic-Family: Voltage:
ABT-Logic ABT-Logic
Input Signals: ViH(min.) = 2.15V ViL(max.) = 0.85V
