5.1.1 CPU core voltages selection, (since V2.2)
For INTEL P5-166Mhz select 3.3V
For INTEL P5-200Mhz select 2.9V
For AMD K6-2-266Mhz select 2.0V
J88:
V-ID4
Pos: 9-10
V-ID3
Pos: 7-8
V-ID2
Pos: 5-6
V-ID1
Pos: 3-4
V-ID0
Pos: 1-2
Rated Output
CPU Core Voltage
Close open open open open 1.30 V
Close open open open Close 1.35 V
Close open open Close open 1.40 V
Close open open Close Close 1.45 V
Close open Close open open 1.50 V
Close open Close open Close 1.55 V
Close open Close Close open 1.60 V
Close open Close Close Close 1.65 V
Close Close open open open 1.70 V
Close Close Open open Close 1.75 V
Close Close Open Close open 1.80 V
Close Close Open Close Close 1.85 V
Close Close Close open open 1.90 V
Close Close Close open Close 1.95 V
Close Close Close Close open 2.00 V
Close Close Close Close Close 2.05 V
Open open open open open Shutdown 0.0V
Open open open open Close 2.10 V
Open open open Close open 2.20 V
Open open open Close Close 2.30 V
Open open Close open open 2.40 V
Open open Close open Close 2.50 V
Open open Close Close open 2.60 V
Open open Close Close Close 2.70 V
Open Close open open open 2.80 V
Open Close Open open Close 2.90 V
Open Close Open Close open 3.00 V
Open Close Open Close Close 3.10 V
Open Close Close open open 3.20 V
Open Close Close open Close 3.30 V
Open Close Close Close open 3.40 V
Open Close Close Close Close 3.50 V
