DIGITAL-LOGIC AG PCCP5 Manual V2.3
127
11.3 AD1816 sound chip
11.3.1 Driver for WIN 3.11
Insert the DRIVER DISK FOR WIN3.1, after starting windows V3.1. Run „SETUP.EXE“ on the driver floppy-
disk A:. Choose „INSTALL“ for all the files to be loaded and system files to be modified. The setup utility al-
lows a different directory to be choosen other than default „ C:\ADISOUND“ for copying. Select „CONTINUE“
to begin copying the files from the disk. After the setup has completed type „EXIT“, restart Windows. You
may configure the device before restarting Windows by choosing „CONFIG“. This „AD1816 I/O Configura-
tion“ allows the user to configure the device to something other than default.
After exiting setup, other configuration changes must be made using the program item drivers under AD1816
Control Panel !
In the Control Panel for the AD1816 the following setting may be made:
Windows Sound System:
Base Port: Address 530 - 53fh
IRQ IRQ5
DMA Play DMA 01
DMA Rec. DMA 00
MPU401:
Base Port: Address 330-331h
IRQ: IRQ9
Sound Blaster System:
Base Port: 220-22fh
Others:
OPL3 Port: 388h-388h
Game Port: 201h-201h (not free on MSM-P5!)
After exiting setup and restarting Windows V3.1 the drivers will be loaded. If there is an I/O, DMA or IRQ
conflict between the audio drivers and other devices in the system, use the Willow Pond Universal Sound-
Comm Driver setup to change any setting, it is located in „drivers“ under Control Panel. The MPU-401 I/O
address and IRQ settings are located in the Roland MPU-401 driver.
