DIGITAL-LOGIC AG PCCP5 Manual V2.3
86
5 DESCRIPTION OF THE CONNECTORS
Flat cable
• 44pin IDE is: IDT Terminal for Dual Row (2.00mm grid) and 1.00mm flat cable
• All others are: IDT Terminal for Dual Row 0.1" (2.54mm grid) and 1.27mm flat cable
Connector Texture Remarks
J01 FAN CPU 2 Pin
J05 LCD 1 (digital 36 Bit) 34 Pin
J06 CRT MONITOR DSub 15 Pin
J11 FLOPPY SMALL 26pin (MICROFLOPPY, not assembled) 26 Pin
J17 COM2 10 Pin
J18 LPT1 26 Pin
J21 FLOPPY NORMAL 34pin 34 Pin
J22 COM1 D-SUB 9 Pin
J23 E-IDE PRIMARY PORT SMALL 44pin (not assembled) 44 Pin
J25 E-IDE PRIMARY PORT NORMAL 40pin 40 Pin
J28 Battery 6 Pin
J31 UTILITY 14 Pin
J32 MOUSE (PS2) 6 Pin
J34/35 PC104-Bus 104 Pin
J36 Slot ISA-Bus 96 Pin
J38 SCSI 2 50 Pin
J40 ETHERNET 10 BASE – 2 2 Pin
J44 POWER +5V, GND, +12V 3 Pin
J56 LCD 2 (optional CRT signals for stackthrough) 8 Pin
J58 Temperature sensor 2 Pin
J58 NTC 100k (TEMPERATURE CONTROL) 2 Pin
J61 KEYBOARD (PS/2) 6 Pin
J62 Video Input 6 Pin
J64 ETHERNET 10 BASE – T 8 Pin
J65 PC104+ Bus 120 Pin
J70 Alternative 33Mhz crystal for AD1816 chip 3 Pin
J71 Sound Line In 3 Pin
J74 COM1 10 Pin
J90 Sound AUX In 2 Pin
J91 COM1 RS422/485 4 Pin
J93 COM2 RS422/485 4 Pin
J95 AUI 8 Pin
J97 USB (not supported) 6 Pin
J98 LAN BSE LED 2 Pin
J99 IDE HDD LED 2 Pin
J102 POWER LED 2 Pin
M1 BIG SIMM 1 (LOW) 72 Pin
M2 BIG SIMM 2 (HIGH) 72 Pin
U75 Flashdisk Socket for M-Systems DOC2000 module 32 Pin
