4.10.4 Memory 65554/65555 Color STN-DD Panels
Hor.
Resol.
Vert.
Resol.
Color
bpp
Refr.
Hz
DCLK
Mhz
MEM
kByte
Cursor
kByte
FB/C
kByte
FB/M
kByte
Video
Input
kByte
Total
with
Video
Total
w/o
Video
640 480 8 60 25.175 300 4.2 120 0 300 724 424
640 480 8 72 31.500 300 4.2 120 0 300 724 424
640 480 8 75 31.500 300 4.2 120 0 300 724 424
640 480 8 85 36.000 300 4.2 120 0 300 724 424
640 480 16 60 25.175 600 4.2 120 0 300 1024 724
640 480 16 72 31.500 600 4.2 120 0 300 1024 724
640 480 16 75 31.500 600 4.2 120 0 300 1024 724
640 480 16 85 36.000 600 4.2 120 0 300 1024 724
640 480 24 60 25.175 900 4.2 120 0 300 1324 1024
640 480 24 72 31.500 900 4.2 120 0 300 1324 1024
640 480 24 75 31.500 900 4.2 120 0 300 1324 1024
640 480 24 85 36.000 900 4.2 120 0 300 1324 1024
800 600 8 60 40.000 469 4.2 188 0 300 960 660
800 600 8 72 50.000 469 4.2 188 0 300 960 660
800 600 8 75 49.500 469 4.2 188 0 300 960 660
800 600 8 85 56.250 469 4.2 188 0 300 960 660
800 600 16 60 40.000 938 4.2 188 0 300 1429 1129
800 600 16 72 50.000 938 4.2 188 0 300 1429 1129
800 600 16 75 49.500 938 4.2 188 0 300 1429 1129
800 600 16 85 56.250 938 4.2 188 0 300 1429 1129
800 600 24 60 40.000 1406 4.2 188 0 300 1898 1598
800 600 24 72 50.000 1406 4.2 188 0 300 1898 1598
800 600 24 75 49.500 1406 4.2 188 0 300 1898 1598
800 600 24 85 56.250 1406 4.2 188 0 300 1898 1598
1024 768 16 60 65.000 1536 4.2 307 0 300 2147 1847
1024 768 16 70 75.000 1536 4.2 307 0 300 2147 1847
1024 768 16 75 78.750 1536 4.2 307 0 300 2147 1847
1024 768 16 85 94.500 1536 4.2 307 0 300 2147 1847
1024 768 24 60 65.000 2304 4.2 307 0 300 2915 2615
1024 768 24 72 75.000 2304 4.2 307 0 300 2915 2615
1024 768 24 75 78.750 2304 4.2 307 0 300 2915 2615
1024 768 24 85 94.500 2304 4.2 307 0 300 2915 2615
1280 1024 16 60 108.0 2560 4.2 512 0 300 3376 3676
1280 1024 16 70 128.0 2560 4.2 512 0 300 3376 3676
1280 1024 16 75 135.0 2560 4.2 512 0 300 3376 3676
1280 1024 16 85 157.5 2560 4.2 512 0 300 3376 3676
1280 1024 24 60 108.0 3840 4.2 512 0 300 4656! 4356!
1280 1024 24 72 128.0 3840 4.2 512 0 300 4656! 4356!
1280 1024 24 75 135.0 3840 4.2 512 0 300 4656! 4356!
1280 1024 24 85 157.5 3840 4.2 512 0 300 4656! 4356!
! means not possible resolution with the 4Mb Video RAM
