4.10.3 Memory 65554/65555/CRT/TFT Panels
Hor.
Resol.
Vert.
Resol.
Color
bpp
Refr.
Hz
DCLK
Mhz
MEM
kByte
Cursor
kByte
FB/C
kByte
FB/M
kByte
Video
Input
kByte
Total
with
Video
Total
w/o
Video
640 480 8 60 25.175 300 4.2 0 0 300 604 304
640 480 8 72 31.500 300 4.2 0 0 300 604 304
640 480 8 75 31.500 300 4.2 0 0 300 604 304
640 480 8 85 36.000 300 4.2 0 0 300 604 304
640 480 16 60 25.175 600 4.2 0 0 300 904 604
640 480 16 72 31.500 600 4.2 0 0 300 904 604
640 480 16 75 31.500 600 4.2 0 0 300 904 604
640 480 16 85 36.000 600 4.2 0 0 300 904 604
640 480 24 60 25.175 900 4.2 0 0 300 1204 904
640 480 24 72 31.500 900 4.2 0 0 300 1204 904
640 480 24 75 31.500 900 4.2 0 0 300 1204 904
640 480 24 85 36.000 900 4.2 0 0 300 1204 904
800 600 8 60 40.000 469 4.2 0 0 300 773 473
800 600 8 72 50.000 469 4.2 0 0 300 773 473
800 600 8 75 49.500 469 4.2 0 0 300 773 473
800 600 8 85 56.250 469 4.2 0 0 300 773 473
800 600 16 60 40.000 938 4.2 0 0 300 1242 942
800 600 16 72 50.000 938 4.2 0 0 300 1242 942
800 600 16 75 49.500 938 4.2 0 0 300 1242 942
800 600 16 85 56.250 938 4.2 0 0 300 1242 942
800 600 24 60 40.000 1406 4.2 0 0 300 1710 1410
800 600 24 72 50.000 1406 4.2 0 0 300 1710 1410
800 600 24 75 49.500 1406 4.2 0 0 300 1710 1410
800 600 24 85 56.250 1406 4.2 0 0 300 1710 1410
1024 768 16 60 65.000 1536 4.2 0 0 300 1840 1540
1024 768 16 70 75.000 1536 4.2 0 0 300 1840 1540
1024 768 16 75 78.750 1536 4.2 0 0 300 1840 1540
1024 768 16 85 94.500 1536 4.2 0 0 300 1840 1540
1024 768 24 60 65.000 2304 4.2 0 0 300 2608 2308
1024 768 24 72 75.000 2304 4.2 0 0 300 2608 2308
1024 768 24 75 78.750 2304 4.2 0 0 300 2608 2308
1024 768 24 85 94.500 2304 4.2 0 0 300 2608 2308
1280 1024 16 60 108.0 2560 4.2 0 0 300 2864 2564
1280 1024 16 70 128.0 2560 4.2 0 0 300 2864 2564
1280 1024 16 75 135.0 2560 4.2 0 0 300 2864 2564
1280 1024 16 85 157.5 2560 4.2 0 0 300 2864 2564
1280 1024 24 60 108.0 3840 4.2 0 0 300 4144! 3844
1280 1024 24 72 128.0 3840 4.2 0 0 300 4144! 3844
1280 1024 24 75 135.0 3840 4.2 0 0 300 4144! 3844
1280 1024 24 85 157.5 3840 4.2 0 0 300 4144! 3844
! means not possible resolution with the 4Mb Video RAM
