4.10.7.1 65554/65555 HiQV64 VGA Driver Resolutions
Date: 8.97
Application: Resolution: Colors: Videomemory:
Windows 3.1 640 x 480 16,256,32k,64k,16M 2MByte
800 x 600 16,256,32k,64k,16M 2MByte
1024 x 768 16,256,32k,64k 2MByte
1280 x 1024 16,256 2MByte
Windows 3.1 640 x 480 16,256,32k,64k,16M 4MByte
800 x 600 16,256,32k,64k,16M 4MByte
1024 x 768 16,256,32k,64k,16M 4MByte
1280 x 1024 16,256,32k,64k 4MByte
Windows 95 640 x 480 16,256,32k,64k,16M 2MByte
800 x 600 16,256,32k,64k,16M 2MByte
1024 x 768 16,256,32k,64k 2MByte
1280 x 1024 16,256 2MByte
Windows 95 640 x 480 16,256,32k,64k,16M 4MByte
800 x 600 16,256,32k,64k,16M 4MByte
1024 x 768 16,256,32k,64k,16M 4MByte
1280 x 1024 16,256,32k,64k 4MByte
1600 x 1280 16,256 4MByte
NT4.0 640 x 480 16,256,32k,64k,16M 2MByte
800 x 600 16,256,32k,64k 2MByte
1024 x 768 16,256 2MByte
1280 x 1024 16 2MByte
NT4.0 640 x 480 16,256,32k,64k,16M 4MByte
800 x 600 16,256,32k,64k,16M 4MByte
1024 x 768 16,256,32k,64k,16M 4MByte
1280 x 1024 16,256,32k,64k 4MByte
4.10.8 Video Input Board V2.1a and older with the VPX3220
The 65554/555 Series integrated configuration reguires only a NTSC/PAL decoder VPX 3220A (from ITT)
and standard DRAMs, without additional memory. The ITT decoder implements a 3 channel video multi-
plexer, which may be software controlled over the I2C bus.
To test the video input, you need to load WIN95 and the DIGITAL-LOGIC’s demonstration program. Connect
up to three cameras or other video sources (PAL or NTSC) to the video input connector and start the system.
In the demo program you may select the signal type and the channels to display on the screen.
Resolutions:
65554 320 x 240 pixel up to 30 images per second
65555 512 x 720 pixel up to 30 images per second
The image may be overlayed or captured and stored into a file. To program this circuit, you need the C&T
65554 manual (to download from the C&T webpage) and the ITT PAL/NTSC decoder datasheet VPX3220A.
From C&T there are also some demo programs and driver examples in C++.
