DIGITAL-LOGIC AG PCCP5 Manual V2.3
146
15.7 Peripheral Setup
1. Press <ENTER> on "PCI/PLUG and PLAY Setup" and the screen as below will display.
AMIBIOS SETUP – PERIPHERAL SETUP
(C) 1996 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Auto
OnBoard Serial Port1 Auto
OnBoard Serial Port2 Auto
OnBoard Parallel port Auto
Parallel Mode ECP
OnBoard IDE Primary
Available Options:
Auto
Disabled
Enabled
ESC:Exit ↑↓:Sel
PgUp/PgDn:Modify
F2/F3 : Color
2. Use <↑> and <↓> to choose the item. Use <PgUp> and
<PgDn> keys to modify the highlighted item.
3. After you have finished with PCI/Plug and Play Setup, press <Esc> to return to the main menu
screen.
15.7.1 A short description of this screen's items follows:
OnBoard FDC This option enables the FDC (Floppy Drive Controller) on the motherboard.
The settings are Auto (AMIBIOS automatically determines if the floppy
conrtoller should be enabled), Enabled or Disabled.
OnBoard Serial Port1 This option specifies the base I/O port address of serial port 1. The settings
are Auto (AMIBIOS automatically determines the correct base I/O address),
Disabled, 3F8h, 2F8h, 2E8h or 3E8h.
OnBoard Serial Port2 This option specifies the base I/O port address of serial port 1. The settings
are Auto (AMIBIOS automatically determines the correct base I/O address),
Disabled, 3F8h, 2F8h, 2E8h or 3E8h.
OnBoard Parallel Port This option specifies the base I/O port address of the parallel port on the
motherboard. The settings are Auto (AMIBIOS automatically determines the
correct base I/O port address), Disabled, 378h, 278h or 3BCh.
Parallel Port Mode This option specifies the parallel port mode. The settings are Normal, EPP or
ECP.
OnBoard IDE This option specifies the channel used by the IDE conrtoller on the board.
The settings are Disabled, Primary, Secondary or Both.
