4.10 VGA, LCD
4.10.1 VGA / LCD Controller C&T65554 and C&T65555
The 65554 / 65555 HiQV64 Flatpanel/CRT VGA controller
• High integrated design (flatpanel/CRT VGA controller, RAMDAC, clock synthesizer)
• PCI 32bit Bus with 33Mhz
• Flexible display memory configurations 2Mbyte standard, 4Mbyte optional
• Videoport ZV, YUV 16Bit Input
• Integrated programmable linear address feature accelerates GUI performance
• Hardware windows acceleration, HW Stretching/Scailing, Auto Panning Support
• 44k BIOS for CRT/FP/Sim FP, Multiple refreshrates, up to 16 Panels in one BIOS, INT15 Hooks
• Mixed 3.3 V / 5.0 V +/- 10 % Operation
• Interface to 3 channels PAL or NTSC videosources with 30 img/sec capturing
• YUV to RGB conversion with zooming up to 8x
• Supports panel resolutions up to 1280 x 1024, including 800x600 and 1024x768
• Supports non-interlaced CRT monitors with resolutions up to 1600 x 1280
• Truecolor / HiColor display capability with flatpanels and CRT monitors up to 1024 x 768 resolution
• Direct interface to Color and Monochrome Dual Drive (DD) and Single Drive (SS) panels (supports 8, 9,
12, 15, 16, 18, 24 and 36 Bit data interfaces)
• Advanced power management features minimize power consumption during:
- Normal operation
- Standby (Sleep) modes
- Panel-Off Power-Saving Mode
• Flexible onboard Activity Timer facilitates ordered shut-down of the display system
• Power Sequencing control outputs regulate application of Bias voltage, +5 V to the panel and +12 V to
the inverter for backlight operation
• SMARTMAP intelligent color to gray scale conversion enhances text legibility
• Text enhancement feature improves white text contrast on flatpanel displays
• Fully Compatible with IBM VGA
