DIGITAL-LOGIC AG PCCP5 Manual V2.3
122
Function: LED SWITCH-STATUS
Number: EEh NOT AVAILABLE ON THIS BOARD!
Description: Sets LED and reads the switches.
Input Values: AH = EEh Function Request
AL 01 Set LEDs only
02 Reads Switches only
03 Set LEDs and read Switches
BL Only for Set LED mode used
LEDs Bit X is LED X
Output Values: AL Switches, if mode is set, otherwise all registers are preserved.
Function: INFORMATION ABOUT INT15-SUPPORT ON THE BOARD
Number: EEh
Description: Gives informations about the supported interrupt 15 functions.
Input Values: AH = EFh Function Request
AL Number of Interrupt, where you need information
SI Password, if you want information about a password
saved Interrupt
Output Values: BX Interrupt-Information Word
BH Version number of Interrupt (0 = not supported)
If there is a Password-saved Interrupt, a zero is shown, if the
password is wrong.
BL Second-Version number.
