E-VISION LASER 5000 SERIES USER MANUAL REV A JANUARY 2018
43
Note:
1. Enable the HDBaseT control function when you desire to use a HDBaseT TX box. (Remove any
RS232 and RJ45/LAN control function from Projector to HDBaseT TX box.) See HDBaseT control
function table.
2. When HDBaseT is enabled, selecting Low Power Mode will auto set to On by HDBaseT.
3. HDBaseT control is disabled when a HDBaseT TX box signal is cutoff.
HDBaseT control function table
Control
Side
Function
Projector Mode
Remark
Low Power
Mode
On(<0.5W)
Low Power
Mode
On by
LAN(<3W)
HDBaseT control Enable
Low Power Mode
On by HDBaseT(<6W)
Projector
Front-IR (wireless) O O O (Can disable by OSD)
Rear-IR (wireless) O O O (Can disable by OSD)
RS-232 O O X
RJ45/LAN X O X
Wired remote O O O
HDBaseT TX Box
HDBT-IR(wireless) X X O
RS-232 X X O
RJ45/LAN X X O
Wired remote X X O
User can con-
nect a wired
remote at the
HDBaseT TX
side to get the
wired remote
function.
O : Enable X : Disable
