Digital Projection
E-VISION LASER 5000 SERIES USER MANUAL REV A JANUARY 2018
61
LED Error Messages
ERROR CODE MESSAGES POWER LED LIGHT LED TEMP LED
Light Source Ready ON OFF OFF
Start Flashing OFF OFF
Cooling Flashing OFF OFF
Over Temperature T1 OFF 1 blinks ON
Over Temperature T2 OFF 2 blinks ON
Over Temperature T3 OFF 3 blinks ON
Over Temperature T4 OFF 4 blinks ON
Over Temperature T5 OFF 5 blinks ON
Thermal Break Sensor error 4 blinks OFF OFF
FAN1 error 6 blinks 1 blinks OFF
FAN2 error 6 blinks 2 blinks OFF
FAN3 error 6 blinks 3 blinks OFF
FAN4 error 6 blinks 4 blinks OFF
FAN5 error 6 blinks 5 blinks OFF
FAN6 error 6 blinks 6 blinks OFF
FAN7 error 6 blinks 7 blinks OFF
FAN8 error 6 blinks 8 blinks OFF
FAN9 error 6 blinks 9 blinks OFF
1W MCU detects scaler stops working 2 blinks OFF OFF
Case Open 7 blinks OFF OFF
Lens Open 7 blinks 1 blinks OFF
DMD error 8 blinks OFF OFF
Color wheel error 9 blinks OFF OFF
Phosphor wheel error 9 blinks 1 blinks OFF
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before restarting
the projector. If the Power or Light source LEDs are still blinking or the Over Temp LED is lit, please
contact your supplying dealer.
Image Problems
Problem: No image appears on the screen
1. Verify the settings on your Laptop or desktop PC.
2. Turn off all equipment and power up again in the correct order.
Problem: The image is blurred
1. Adjust the Focus on the projector.
2. Press the Auto button on the remote control or projector.
3. Ensure the projector-to-screen distance is within the specified lens range.
4. Check that the projector lens is clean.
Problem: The image is wider at the top or bottom (trapezoid effect)
1. Position the projector so it is as perpendicular to the screen as possible.
2. Use the Keystone button on the remote control or projector to correct the problem.
