E-VISION LASER 5000 SERIES USER MANUAL REV A JANUARY 2018
69
Supported Frequencies For 3D mode
The unit automatically determines PC signals to select the appropriate resolution. Some signals may
require manual adjustment.
Input Signal for D-SUB/HDMI/DVI-D
SIGNAL RESOLUTION REFRESH RATE(HZ)
SVGA 800 X 600 60/120
XGA 1024 X 768 60/120
HDTV(720P) 1280 X 720 60/120
WXGA 1280 X 800 60/120
True 3D Video Compatibility table
Input
Resolutions
HDMI 1.4a
3D Input
Input timing
1280 X 720P @ 50Hz Top - and - Bottom
1280 X 720P @ 60Hz Top - and - Bottom
1280 X 720P @ 50Hz Frame packing
1280 X 720P @ 60Hz Frame packing
1920 X 1080i @50 Hz Side- by-Side (Half)
1920 X 1080i @60 Hz Side- by-Side (Half)
1920 X 1080P @24 Hz Top - and – Bottom
1920 X 1080P @24 Hz Frame packing
HDMI 1.3
1920 x 1080i @ 50Hz
1920 x1080i @ 60Hz
1280 x 720P @50Hz
1280 x 720P @60Hz
Side-by-Side(Half) SBS mode is on
1920 x 1080i @ 50Hz
1920 x1080i @ 60Hz
1280 x 720P @50Hz
1280 x 720P @60Hz
Top-and-Bottom TAB mode is on
480i HQFS
3D format is Frame
sequential
Note:
3D glasses must support up to 144Hz.
