Command Group 02
ASCII HEX Function Description Return Value
VXXS0201 56h Xh Xh 53h 30h 32h 30h 31h 0Dh Select RGB P/F
VXXS0203 56h Xh Xh 53h 30h 32h 30h 33h 0Dh Select DVI P/F
VXXS0204 56h Xh Xh 53h 30h 32h 30h 34h 0Dh Select Video P/F
VXXS0206 56h Xh Xh 53h 30h 32h 30h 36h 0Dh Select HDMI P/F
VXXS0207 56h Xh Xh 53h 30h 32h 30h 37h 0Dh Select BNC P/F
VXXS0209 56h Xh Xh 53h 30h 32h 30h 39h 0Dh Select HDMI 2 P/F
VXXS0212 56h Xh Xh 53h 30h 32h 31h 32h 0Dh Select HDMI 3/MHL P/F
VXXS0215 56h Xh Xh 53h 30h 32h 31h 35h 0Dh Select HDBaseT P/F
VXXG0220 56h Xh Xh 47h 30h 32h 32h 30h 0Dh Get Current Source
Return
1:RGB
3:DVI
4:Video
6:HDMI
7:BNC
9:HDMI2
12:HDMI3/MHL
15:HDBaseT
Pn/F
Command Group 03
ASCII HEX Function Description Return Value
VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh Get Scaling
0:Fill
1:4:3
2:16:9
3:Letter Box
4:Native
5:2.35:1
Pn/F
VXXS0301n 56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh Set Scaling
0:Fill
1:4:3
2:16:9
3:Letter Box
4:Native
5:2.35:1
P/F
VXXG0302 56h Xh Xh 47h 30h 33h 30h 32h 0Dh Blank Pn/F
VXXS0302n 56h Xh Xh 53h 30h 33h 30h 32h nh 0Dh Blank P/F
VXXG0304 56h Xh Xh 47h 30h 33h 30h 34h 0Dh Freeze On Pn/F
VXXS0304n 56h Xh Xh 53h 30h 33h 30h 34h nh 0Dh Freeze On P/F
VXXG0305 56h Xh Xh 47h 30h 33h 30h 35h 0Dh Volume n=0~10 Pn/F
VXXS0305n 56h Xh Xh 53h 30h 33h 30h 35h nh 0Dh Volume n=0~10 P/F
VXXG0308 56h Xh Xh 47h 30h 33h 30h 38h 0Dh Projection Mode
0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling
Pn/F
VXXS0308n 56h Xh Xh 53h 30h 33h 30h 38h nh 0Dh Projection Mode
0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling
P/F
VXXG0309 56h Xh Xh 47h 30h 33h 30h 39h 0Dh
Get vertical
keystone value
n=-30~+30 Pn/F
