36
OPERATION
The following items are saved (for all sources, not just the active source):
• Brightness / Contrast
• Color Saturation / Color Tint
• Sharpness (all settings in sub-menu)
• Noise Reduction (all settings in sub-menu)
• Color Space
• Video Standard
• Gamma
• DLP Frame Rate
• Color Gamut
• Adaptive Contrast
• RGB Adjust (all settings in sub-menu)
The settings that are saved are the same as those saved with the Save Settings command (see above).
Brightness: On your external test pattern source, select a PLUGE pattern. (PLUGE is an acronym for “Picture Line-
Up Generation Equipment.”) Figure 4-3 shows a typical PLUGE pattern.
Below Black
Above Black
Figure 4-3: Typical PLUGE Pattern for Adjusting Brightness
