Digitalchina Networks DCS-3950 series User Manual

374
DCS-3950 series Ethernet switch manual
Command mode: Admin Mode
Displayed information Explanation
Ethernet1/2 Port name
default cos:0 Default CoS value of the port.
DSCP Mutation Map: Default DSCP
Mutation Map
Port DSCP map name
Attached policy-map for Ingress: p1 Policy name bound to port.
Displayed information Explanation
Ethernet0/0/2 Port name
buffer size of 4 queue:256 256 256 256 Available buffer number for all 4 queues
out on the port, this is a fixed setting that
cannot be changed.
Displayed information Explanation
Cos-queue map:
Cos 0 1 2 3 4 5 6 7
Queue 1 1 2 2 3 3 4 4
CoS value to queue mapping.
Queue and weight type:
q1 q2 q3 q4 QType
1 2 4 8 WFQ
Queue to weight mapping.
Displayed information Explanation
Ethernet1/2 Port name
Attached policy-map for Ingress: p1 Policy map bound to the port.
Displayed information Explanation
Ethernet1/2 Port name
ClassMap Name of the Class map
Classified Total data packets match this class map.
In-profile Total in-profile data packets match this
class map.
out-profile Total out-profile data packets match this
class map.
24.4.1.4 show mls qos maps
Command：show mls qos maps [cos-dscp | dscp-cos | dscp-mutation |
policed-dscp]
Function: Display mapping configuration information for QoS.
Parameter: cos-dscp CoS for CoS-DSCP; dscp-cos DSCP for DSCP-CoS,
