Digitalchina Networks DCS-3950 series User Manual

33
DCS-3950 series Ethernet switch manual
port-channel Type interface
port-channel
<port-channel-nu
mber> command
under Global
Mode.
Switch(Config-if-
port-channelx)#
Configure
port-channel
related
settings such
as duplex
mode, speed,
etc.
Use the exit
command to
return to
Global Mode.
4.2.1.1.5 VLAN Mode
Using the vlan <vlan-id> command under Global Mode can enter the corresponding
VLAN Mode. Under VLAN Mode the user can configure all member ports of the
corresponding VLAN. Run the exit command to exit the VLAN Mode to Global Mode
4.2.1.1.6 DHCP Address Pool Mode
Type the ip dhcp pool <name> command under Global Mode will enter the DHCP
Address Pool Mode prompt ‘Switch(Config-<name>-dhcp)#’. DHCP address pool
properties can be configured under DHCP Address Pool Mode. Run the exit command to
exit the DHCP Address Pool Mode to Global Mode.
4.2.1.1.7 ACL Mode
ACL type Entry Prompt Operates Exit
Standard IP
ACL Mode
Type ip
access-list
standard
command
under Global
Mode.
Switch(Config
-Std-Nacl-a)#
Configure
parameters for
Standard IP
ACL Mode
Use the ‘exit’
command to
return to Global
Mode.
Extended IP
ACL Mode
Type ip
access-list
extanded
command
under Global
Mode.
Switch(Config
-Ext-Nacl-b)#
Configure
parameters for
Extended IP
ACL Mode
Use the ‘exit’
command to
return to Global
Mode.
4.2.1.2 Configuration Syntax
DCS-3950 series Switch provides various configuration commands. Although all the
commands are different, they all abide by the syntax for DCS-3950 series Switch
configuration commands. The general commands format of DCS-3950 series Switch is
