DCS-3950 series Ethernet switch manual
Command mode: Admin Mode
Usage Guide: The ‘show running-config’ is used to verify whether the users had entered
the configurations correctly.
Example:
Switch#show running-config
5.2.5.9 show startup-config
Command: show startup-config
Function: Display the switch parameter configurations written into the Flash memory at
the current operation; those are usually also the configuration files used for the next
power-up.
Default: If the configuration parameters read from the Flash are the same as the default
operating parameter, nothing will be displayed.
Command mode: Admin Mode
Usage Guide: There are some differences between the commands show
running-config and show startup-config. Newly configured options can be shown
through the show running-config command, but can not be show through show
startup-config.The result will be the same for the both commands only if the write
command has been issued, and the current configurations have been preserved in the
system flash.
5.2.5.10 show switchport interface
Command: show switchport interface [ethernet <interface-list>]
Function: Show the VLAN port mode, VLAN number and Trunk port messages of the
VLAN port mode on the switch.
Parameter: <interface-list> is the port number or port list, which could be maximum of
0/0/1 port in the switch
Mode: Privileged configuration mode.
Example: To show vlan configurations of interface 0/0/1.
Switch#show switchport interface ethernet 0/0/1
Ethernet0/0/1
Type:Universal
Mac addr num:-1
Mode :Access
Port VID :1
Trunk native Vlan :1
Trunk allowed Vlan : ALL
Parameters Descriptions
Ethernet0/01 The port name of the Ethernet interface.
Type The state of the current interface.
Mac addr num The maximum size of the table of MAC addresses that the
