Digno Keitai 3 - Materials

106
Materials
DIGNO
®
ケータイ3 (Keitai 3)
Outer Case
(LCD Case)
PC + GF resin + SUS sheet metal/UV cured
acrylic coating
Outer Case
(Key Case)
PC + GF resin/UV cured acrylic coating
Outer Case
(Hinge Cover)
PC resin/UV cured acrylic coating
Back Cover
PC resin + silicon rubber/UV cured acrylic
coating + polyurethane print
Rear side of
Back Cover
(black sheet)
PET resin
Outer Case
(LCD Rear
Plate)
PMMA resin (in-mold)/UV cured acrylic
coating
Infrared Port
Window
PMMA resin
Camera
Window
PMMA + PC resin/hard coating
Upper part of
vibrator on
lower left of
camera (black
sheet)
PET resin
Multi
Selector (Key
Top)
PET resin/UV cured resin
Key Sheet PET resin/UV cured resin
Cushion
(Under
Numeric
Keypad)
PET resin/UV cured resin
Window
Panel (Main),
Camera Plate
PMMA + PC resin/hard coating
Side Key PC resin/UV cured acrylic coating
Key Gasket Silicon rubber + SUS sheet metal
Main Antenna PC + ABS resin + LDS
Sub Antenna PC + ABS resin + LDS
Screws SWCH/trivalent chromate
SD Card Slot
Cover
SUS sheet metal
SD Card Slot
(Terminal
Portion)
Copper alloy/Ni + Au plating
SD Card
Slot (Resin
Portion)
LCP resin
USIM Card
Slot Cover
SUS sheet metal
USIM Card
Slot (Terminal
Portion)
Copper alloy/Ni + Au plating
USIM Card
Slot (Resin
Portion)
LCP resin
Battery
Terminal
(Resin
Portion)
LCP resin
Battery
Terminal
(Metal
Portion)
Copper alloy/Ni + Au plating
Charging
Terminal
(USB Type-
C Connector
Resin Portion)
LCP resin
Charging
Terminal
(USB Type-
C Connector
Metal Portion)
Copper alloy/Ni + Au plating
Black part
next to
Battery
Terminal
PC resin
Holder Card PP resin
Shield Case SUS sheet metal/Sn plating
Water
Wetting
Sensing Sheet
PET resin
Name Plate PET resin
Battery (KYBAQ1)
Outer Casing
(Resin
Portion)
PC resin
Outer Casing
(Metal
Portion)
Aluminum
Print Label PET resin/matte coating
Terminals Copper alloy/Ni + Au plating
Water
Wetting
Sensing Sheet
PET resin
