C • User Interface
Doc. 065207-02 9/08 133
C.2.3 Regulators Screen
Use the REGULATORS screen to monitor various pressure readings for the
ASE 150. You cannot edit any information on this screen.
NOTE Select the unit of measure for on-screen pressure
readings on the
SETUP screen (see Section C.1.3).
NOTE The
COMPRESSION and AUTOSEAL pressure
readings are zero unless a run is in progress.
Figure C-8. Regulators Screen
Parameter Description Specification
SYSTEM
Indicates the internal system pressure. 0.34 ± 0.02 MPa
(50 ± 3 psi)
COMPRESSION
Indicates the pressure applied when the oven is
compressed
0.90 ± 0.03 MPa
(130 ± 5 psi)
BOTTLE
Indicates the pressure applied to the solvent
reservoir
0.03 to 0.07 MPa
a
(4 to 10 psi)
a. Nominally set for 0.04 MPa (6 psi). The pressure may increase during periods of system
inactivity, but will return to a value within the specification range as soon as a run begins.
AUTOSEAL
Indicates the pressure applied when the
AutoSeal air cylinder is actuated
0.14 ± 0.01 MPa
(21 ± 2 psi)
SYSTEM
COMPRESSION
BOTTLE
AUTOSEAL
50PSI
0PSI
6PSI
0PSI
