Dionex ASE 150 - 2 • Description; 2.1 Operating Features

Doc. 065207-02 9/08 7
2 • Description
2.1 Operating Features
Figure 2-1 illustrates the main operating features of the ASE 150 Accelerated
Solvent Extractor.
Figure 2-1. ASE 150 Operating Features
1
Solvent Reservoir
Control Panel
2
Door OPEN Lever
4
5
6
3
1
2
Oven
Sample Cell
Waste Bottle
Collection Vessel
(250-mL bottle shown)
Drip Tray
Needle UP/DOWN Switch
3
4
5
6
7
8
9
7
8
9
