3 • Operation and Maintenance
Doc. 065207-02 9/08 41
3.1.7 Installing the Waste Bottle
Use a 250-mL collection bottle (without a cap) for the waste bottle.
1. Open the waste compartment door.
2. Tilt the waste bottle at a slight angle
and position it below the built-in
bottle cap.
3. While being careful not to bend the
tubing that extends from the bottle
cap, insert the bottle into the bottle
cap.
4. Tilt the cap and bottle toward you
and screw the bottle into the cap.
5. Hand-tighten the bottle onto the cap
to ensure a good seal.
6. Release the bottle, allowing it to
swing gently into place.
7. Close the waste compartment door.
Figure 3-11. Installing the Waste Bottle
