ASE 150 Operator’s Manual

86 Doc. 065207-02 9/08

5.8 Rebuilding the Static Valve

Leaking from the source needle into the collection vessel during the static cycle

indicates that the static valve is worn and must be rebuilt. The rebuild procedure

consists of replacing a few parts (an O-ring, a filter, and two seals) and then

cleaning the inside of the valve body.

Before proceeding, check that the following kits are on hand. The kits contain the

replacement parts and special tools required to rebuild the valve.

• Order a Static Valve Repair Kit (P/N 068115) each time the valve requires

rebuilding.

• Order a Static Valve Tool Kit (P/N 068116) only the first time the valve

requires rebuilding. Figure 5-19

illustrates each tool.

Part Number Item Quantity

065254 ASE 150/ASE 350 Static Valve Repair

Kit Instructions

066165 High-pressure flangeless seal 2

067326 Perlast® O-ring 1

067327 Zirconium filter 1

Table 5-1. Static Valve Repair Kit Contents

Part Number Static Valve Tool Quantity

049293 Tubing, orange (extension tubing) 60.96 cm (24 in)

057395 Union (for extension tubing) 1

067394 Piston-side seal insertion tool 1

067395 Inlet-side seal insertion tool 1

068117 Alignment tool 1

068118 Spacer tool 1

068119 Push screw tool 1

068245 Seal removal tool 1

Table 5-2. Static Valve Tool Kit Contents
